AC / DC 3 Phase / 1 Phase Stator Core Assembly Machine For Stator Coil Winding

  • 1
  • 2

Brand Name : SMT

Model Number : SMT-R160

Certification : ISO9001/SGS Audit

Place of Origin : China

MOQ : 1 Set

Price : Negotiable

Payment Terms : T/T, L/C

Supply Ability : 1pcs / 32 - 51 days

Delivery Time : 32 - 51 days

Packaging Details : Plywood Box With Sealing Bag

Name : AC / DC 3 Phase / 1 Phase Stator Core Assembly Machine For Stator Coil Winding

Color : White

Wire Speed : ≤3200r/min

Flier : 200mm

Transfer Number : 2-6pcs

Power Supply : 220v/50/60Hz 7Kw

Weight : 750kg

Dimension : (L)1800X(W)1100X2200mm

Winding Head : 1-8

Air Pressure : ≥0.4MPa

Transfer Distance : ≥170mm

Contact Now

AC / DC 3 Phase / 1 Phase Stator Core Assembly Machine For Stator Coil Winding

Multistrand Type Coil Winding Machine is specially designed for multiple wire parallel coil winding such as alternator, servo motor and three phase motor. Multistrand Type Coil Winding Machine adopts special purpose controller which could set the function of arraying direction, winding start point, slow starting,slow ending, sides stop, auto width, auto reset, ect.

(2)Technical parameter of stator coil winding machine

Product name stator coil winding machine
Swing diameter ≤350mm
Effective length of tooling ≤400mm
Parallel wire number ≤16 pcs
Wire diameter 0.2~1.5mm
Max RPM 1600RPM
Power supply 220V/50/60Hz 1.5Kw
Air pressure 0.4~0.6MPa
Machine Weight 900Kg
Machine Dimension 1550mm*1250mm*1550mm


(3) Machine function and characteristic of stator coil winding machine
This Stator Coil Winding Machine is specially designed for multiple wire parallel coil winding such as alternator, servo motor and three phase motor.
This stator coil winding machine adopts special purpose controller which could set the function of arraying direction, winding start point, slow starting, slow ending, sides stop, auto width, auto reset, ect.
The coil winding machine saves labor and cost.

(4)Competitive advantages:
This machine could set the function of arraying direction, winding start point, slow starting, slow ending, sides stop, auto width, auto reset, ect..
Variety of application, easy operation.
We have Overseas Service Center.
It is suitable for rotor or stator with different model number and dimension.

The operation and tooling change process is easy.
We could customize machine for our customer as per their requirement.
We directly supply our machines to many countries, like USA, France, Turkey, Iran, India, Brazil, Argentina, Mexico etc.

AC / DC 3 Phase / 1 Phase Stator Core Assembly Machine For Stator Coil Winding
